Specification
|
Complete Machine |
||
|
Model No. |
KOT-0430U-CA4P (P/N:KOT-430P-010) |
|
|
Series |
OT |
|
|
Display Type |
16:9 Ratio 43" TFT-LCD |
|
|
Active Area |
942.7*531(mm) |
|
|
Monitor Dimensions (W*H*D) |
1004.9*592*143.7(mm) |
|
|
Suggested Resolution |
3840*2160@ 60Hz |
|
|
Support Colors |
1.07G(8bits+FRC) |
|
|
Brightness (Typ.) |
Pure LCD Panel |
495cd/m2 |
|
With Touch Monitor |
420cd/m2 |
|
|
Response Time (Typ. ) |
8ms |
|
|
Viewing Angle(Typ.at CR＞10) ） |
Horizontal(left/right) |
89°/89° |
|
Vertical(up/down) |
89°/89° |
|
|
Contrast Ratio (Typ.) |
1200:1 |
|
|
Video Input |
DP\HDMI |
|
|
Frequency (H/V) |
69～75KHz / 57～62Hz |
|
|
Power Supply |
Type: External brick Display voltage: DC 24V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz(Note: The power adapter of this product is optional. If consumers use a power adapter for power supply, they should purchase a power adapter that has been recognized by CCC and meets the standard requirements.) |
|
|
Environment |
Operating Temp. |
0～50°C |
|
Operating RH |
20%～80% |
|
|
Storage Temp. |
-10～60°C |
|
|
Storage RH |
10%～90% |
|
|
MTBF |
≥30,000 Hours |
|
|
LED Back Light Life (Typ.) |
≥30,000 Hours |
|
|
Weight（ N.W/G.W ） |
22.5Kg(1pcs) / 26.8Kg(1pcs in one package) |
|
|
Package dimensions |
1100*200*710(mm)(1pcs in one package) |
|
|
Power Consumption |
Standby Power: ≤3W / Operating Power: ≤160W |
|
|
Mount Interface |
1.VESA M6 400*400(mm) 2.Mount bracket, horizontal or vertical mount |
|
|
OSD Control |
Buttons |
AUTO,+,POWER,-,MENU |
|
Function |
Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset |
|
|
Agency approvals |
CCC, UL, FCC, CE, CB, RoHS |
|
|
Regular Warranty |
1 year |
|
|
Touch Screen |
|
|
Touch Type |
43" Capacitive touch screens |
|
Touch input |
USB |
|
Response Time |
≤14ms |
|
Hardness |
6H |
|
Light Transmittance |
≥85% |
|
Support System |
XP,WIN7,WIN8,WIN10,Linux,Android |
|
Active Area |
942.9*531.3±0.5(mm) |
|
Thickness |
3.75±0.2(mm) |
|
Touch Test |
≥50,000,000 times |
|
Input Voltage |
DC 5V±5% |
